This manual is for ZerOS, the operating system for FLX, FLX S and ZerOS Server.

This manual is correct as per ZerOS 7.13 software.

ZerOS is regularly updated to bring new features and to keep your console stable and secure. Software updates are free of charge and can be downloaded from zero88.com/zeros. It is recommended to always be running the latest release of ZerOS.

Please read this manual before use, especially the Warnings & Safety section.

E&OE. Vari-Lite reserve the right to make changes to the equipment and specification described in this manual without prior notice.
